Smart Card Chip Reader
· Ulian reader supports contact/contactless CPU cards.
· ISO7816 standard (T=0, T=1), supports reverse character protocol.
· ISO14443 Type A/B MIFARE.
· Uses LINUX system, supports secondary development.
- Information
Product Introduction
Introduction of Smart Card Chip Reader
Smart card chip personalization reader is an efficient and reliable smart card reader/writer that supports both contact and contactless reading and writing methods to meet different application requirements. Smart card reader module connects to the card chip through physical contact to ensure the security and stability of data transmission, and is widely used in finance, access control, and identity authentication. Contactless smart card reader machine uses radio frequency identification technology to read data without direct contact with the card, and is suitable for fast and efficient payment, public transportation, and employee attendance. Whether contact or contactless, smart card chip reader system provides high security and high-speed transmission, providing reliable support for smart card applications.
Technical Parameters
| Contact Reader | |
| Standard |
|
| Power | Adjustable power supply voltage, 1.8V, 3V, 5V. |
| PPS rate | Optional rate, 11/12/13/18/94/95/96/97 |
| Clock frequency (M) | Optional clock frequency, 3.6/4/4.5/5.2/6/7.2/9/12/18/36 |
| Communication | 10M/100M Ethernet |
| Function |
|
| Contactless Reader | |
| Standard | Support contactless CPU card, ISO14443 Type A/B, MIFARE |
| Wave Frequency | 13.56MHz |
| Baud Rate | 106~848K |
| Communication | 10M/100M Ethernet |
